The is a professional grade shotgun microphone. Based on the latest ‘Film industry’ technology, the is designed specifically for use with high quality Digital Video Cameras Features Studio recording quality.
Key Features
• Rugged fibre-reinforced ABS construction.
• 9 V battery operation.
• Custom designed integral ‘wind’ screen.
• Condenser Microphone.
• Low noise circuitry.
• Low handling noise.
• Integral hot shoe mount & zip pouch.
• Designed & manufactured in Australia.
• Full 2 year guarantee.
OperationPower
The is designed to operate from a 9 V battery (ANSI:1604A or IEC:6LR61). The battery is conveniently located within the support arm of the microphone.
A fully removable access cover and a 1-way insertion mechanism ensure ease of loading. The battery willprovide more than 100 hrs. of continuous use due to alow consumption of only 5.0 mA.
Output Impedance
The microphone will operate satisfactorily into a loadimpedance as low as 1 k§Ù. If a load below this is used,the output signal level will be reduced.
Specifications
Acoustic Principle: Line plus
Gradient Directional Pattern: Super-Cardioid Frequency range: 40 Hz ~ 20 000 Hz selectable HPF @ 80 Hz/12 dB/octave
Output Impedance: 200 Ω
Signal/Noise ratio DIN/IEC 651: 74 dB (1 kHz rel 1 Pa; per IEC651, IEC268-15)
Equivalent Noise: 20 dB SPL (per IEC651, IEC268-15)
Maximum SPL: 134 dB (@ 1% THD into 1 kΩ)
Sensitivity at 1 kHz into 1 kΩ: -3 dB re 1 Volt/Pascal (15 mV @ 94 dB SPL) +/- 2 dB (at 1 kHz in free field into open circuit)
Dynamic Range - DIN/IEC 651: 114 dB (per IEC651, IEC268-15)
Power (Supply voltage): 9 V DC Alkaline Battery (ANSI:1604A or IEC:6LR61)
Current consumption: 5 mA Battery Life: >100 hours
Output Connection: Stereo mini jack plug - Ø3.5 mm.
Weight - no battery: 176 grm. (6.21 oz.)
Dimensions: 250mm(L)x65mm(W)x102mm(H)
